New Volvo video interface for Sensus Connect with 8.7inch vertical monitor with rear and front camera inputs Expand

Volvo video interface for Sensus Connect with 8.7inch vertical monitor with rear and front camera inputs

Volvo Volvo

CI-RL4-SC15

New

Volvo video interface for Sensus Connect with 8.7inch vertical monitor with rear and front camera inputs

More details

shipped in 24 h

€ 294,26

tax incl.

Worldwide shipping

24/48h Delivery

Secure payment

Car electronic experts since 1990

Volvo video interface for Sensus Connect with 8.7inch vertical monitor with rear and front camera inputs

v.LiNK video inserter compatible with Volvo XC90 model year 2015 with Sensus Connect navigation and 12.3 inch monitor. For connection of 2 different video sources, 1 rear-view camera and 1 front camera

Product features:

  • Video-insertion for factory infotainment systems
  • 1 Rear-view camera CVBS video-input
  • 1 CVBS front camera video-input
  • 2 CVBS video-inputs for after-market devices (e.g. DVD-Player, DVB-T tuner, .)
  • Automatic switching to rear-view camera input on engagement of reverse gear
  • Automatic front camera switching after reverse gear for 10 seconds
  • Video-in-motion (ONLY for connected video-sources)
  • Activatable Parking Guide Lines for Rear-View Camera (not all vehicles)
  • Compatible with factory rear-view camera
  • AV-inputs PAL/NTSC compatible



Compatibility:

ModelRadio / Navigation
  XC90 from 2015

Sensus Connect with 8.7inch vertical monitor

  S60 from 2020
  S90 from 2017
  V60 from 2016
  V90 from 2016
  XC40 from 2019
  XC60 from 2018




Limitations:

  • The interface inserts ONLY video signals into the infotainment. For sound use the possibly existing factory-audio-AUX-input or a FM-modulator.
  • If 2 AV-sources shall be connected to the infotainment an additional electronic is required.
  • Automatically switching-back from inserted video to factory rear-view camera is only possible while the reverse gear is engaged. To delay the switch-back an additional electronic part is required.


Specifications:

BATT/ACC range7V – 25V
Stand.by power drain<10mA
Power0.4A@12V
Video input0.5V˜2V
Video input formatsNTSC
Temperature range-40°C to +85°C
Dimensions118 x 25 x 104 mm (W x H x D)

Connections:

  • Video-insertion: 4-pin HSD
  • Power and CAN-bus: Plug & play
  • Video-input (2x): RCA connector
  • Rear and front camera-input: RCA connector


Remember that in some states it is illegal to use the video in motion while driving!


The manufacturer of this item, and the administrator of this site will not be responsible for any damage to persons or property caused by improper use or in terms contrary to the laws.

VolvoS60, XC90
CategoryRear View Camera Interfaces, Video integration
