Video interface for Maserati N3 Magneti Marelli (only)

Video Interface for Maserati N3 Magneti Marelli (only).

 Watch any video source on your original screen

v.LINK video insertion compatible with Citroen and Peugeot vehicles with navigation with colour display and 10pin LVDS monitor connector. For connection of 2 different video sources (upgraded devices, for example DVD player, DVB-T tuner) and 1 rear-view camera.

Product features:

• Video-insertion for factory-infotainment monitors
• 2 CVBS video-inputs for after-market devices (e.g. DVD-Player, DVB-T tuner, .)
• Built-in audio-switch (no audio-insertion)
• Rear-view camera CVBS video-input
• Automatic switching to rear-view camera input on engagement of reverse gear
• Video-in-motion (ONLY for connected video-sources)
• Compatible with factory rear-view camera
• AV-inputs PAL/NTSC compatible


Compatibility:

Limitations:

The interface inserts ONLY video signals into the infotainment. For sound use the possibly existing factory-audio-AUX-input or a FM-modulator.

Automatically switching-back from inserted video to factory rear-view camera is only possible while the reverse gear is engaged. To delay the switch-back an additional electronic part is required.

Specifications:

Connections:

• Video-insertion: 10-pin HSD
• Power and CAN-bus: Plug & play
• Video-input (2x): RCA connector
• Rear-view camera-input: RCA connector
• Audio-switch: 2-channel RCA connector

Remember that in some states it is illegal to use the video in motion while driving!

The manufacturer of this item, and the administrator of this site will not be responsible for any damage to persons or property caused by improper use or in terms contrary to the laws.
