Mount-on shutter rear-view camera with 5 IR LEDs, audio
CI-CAM-P-AE150PHR
New
Mount-on shutter camera PAL 1/3 inch Sony Super HAD CCD high resolution with wide 150° diagonal angle, 5 IR LEDs for nightvision. Switchable image mirror function.
Valutazione: Scrivi per primo una recensione!
1/3 inch PAL CCD-HR mount-on shutter camera with awning, 5 LEDs for nightvision, microphone.
Features:
Dimensions:
Limitations:
In order for the camera to work, an additional system of cable, not included in the delivery, is necessary: it is CI-CAB-RV4-**S, available in different length (10cm, 5m, 10m, 15m, 20m, 40m).
The 4pin Mini-DIN plug with screw thread and CV allocation can be directly connected to a camera-switch or to some monitor for rear-view system. For the stand-alone working of other products, the optional adapter to RCA CI-CAB-4P-RCA is required.
IMPORTANT:
Don't forget to order the cable system CI-CAB-RV4-**S, and eventually the adapter to RCA CI-CAB-4P-RCA!
Features:
- Mount-on shutter rear-view camera with awning
- 100% waterproof
- 20m cable with cinch connector
- 5 IR-LED for nightvision
- Sensor type 1/3 Colour Sony CCD
- Image system PAL
- Resolution 470000 px
- TV-Lines 580
- 2.45mm, F2.0 lens
- 0.0 Lux
- Angle: horizontal 120°, vertical 90°, diagonal 150°
- Mirrored image (switchable)
- 4pin Mini-DIN connector
- 90cm cable with rubber grommet
- Power supply 12V
- Power consumption 150mA
- Range of working temperature: -20°C to +70°C
- Weight 387g
Dimensions:
- Overall (L×W×D) 69×42×58 mm
Limitations:
In order for the camera to work, an additional system of cable, not included in the delivery, is necessary: it is CI-CAB-RV4-**S, available in different length (10cm, 5m, 10m, 15m, 20m, 40m).
The 4pin Mini-DIN plug with screw thread and CV allocation can be directly connected to a camera-switch or to some monitor for rear-view system. For the stand-alone working of other products, the optional adapter to RCA CI-CAB-4P-RCA is required.
IMPORTANT:
Don't forget to order the cable system CI-CAB-RV4-**S, and eventually the adapter to RCA CI-CAB-4P-RCA!
| Category | Cameras RVC |
