Video interface for Opel Navi 50 (MediaNav), Navi 80 IntelliLink (Rlink) Expand

Video interface for Opel Navi 50 (MediaNav), Navi 80 IntelliLink (Rlink)

Opel Opel

CI-RL1-RLK-OP

New

Video interface for Navi 50 (MediaNav) and Navi 80 IntelliLink (Rlink) Opel.

More details

shipped in 24 h

€ 245,08

tax incl.

Worldwide shipping

24/48h Delivery

Secure payment

Car electronic experts since 1990

Video interface for Navi 50 (MediaNav) and Navi 80 IntelliLink (Rlink) Opel.

Opel Navi 50 IntelliLink
Opel Navi 80 IntelliLink

This interface allows you to integrate an external video source to your cars factory fitted screen. Once connected it gives you the ability to connect an in car DVD player, games console (such as Playstation2 or Xbox), iPod video, digital TV tuner, rear view camera, car navigation GPS etc to keep your passengers entertained.

The multimedia interface has 2 video inputsand a rear camera input The interface does not replace your original system - it offers perfect integration to maintain your OEM appearance. The interface connects directly to the head unit and you can select video source using the provided switch to change video source (depending by the systems):




Product features:

  • Video-insertion for factory-infotainment monitors
  • 2 CVBS video-inputs for after-market devices (e.g. DVD-Player, DVB-T tuner, .)
  • Rear-view camera CVBS video-input
  • Automatic switching to rear-view camera input on engagement of reverse gear
  • Video-in-motion (ONLY for connected video-sources)
  • Video-inputs only NTSC compatible




Compatibility:

ModelRadio / Navigation
Movano 2016 >Navi 50 (MediaNav Model: LAN52xxWRx)
Navi 80 IntelliLink (Rlink)
Vivaro 2016 - 2019



Limitations:

The interface inserts ONLY video signals into the infotainment. For sound use the possibly existing factory-audio-AUX-input or a FM-modulator.

Automatic switch to factory rear-view camera only while reverse gear is engaged. To delay the switch reset, additional electronics is required.



Specifications:





BATT/ACC range7V – 25V
Stand.by power drain<25mA
Power200mA
Video input0.7V˜1V
Video input formatsPAL/NTSC
Temperature range-40°C to +85°C
Dimensions video-box113 x 22 x 96mm (W x H x D)
Dimensions CAN-box73 x 22 x 45mm (W x H x D)


Connections:

  • Video-insertion: ribbon-cable
  • Power: open cable ends
  • Video-input (2x): female RCA connector
  • Rear-view camera-input: female RCA connector




Remember that in some states it is illegal to use the video in motion while driving!


The manufacturer of this item, and the administrator of this site will not be responsible for any damage to persons or property caused by improper use or in terms contrary to the laws.

OpelMOVANO, VIVARO
CategoryRear View Camera Interfaces, Video integration
