New Audi from MY2016 exchange rear door opener handle with integrated camera and switchable guide-lines Expand

Audi from MY2016 exchange rear door opener handle with integrated camera and switchable guide-lines

Audi Audi

CI-VSC-E-AU15-AU

New

Audi from MY2016 exchange rear door opener handle with integrated camera and switchable guide-lines

More details

€ 138,52

tax incl.

Worldwide shipping

24/48h Delivery

Secure payment

Car electronic experts since 1990

Vehicle-specific exchange rear door opener handle with integrated camera and switchable guide-lines. Easy assembling by replacing the factory rear door opener handle. Professional connector cable with enough length and automotive plug connection. Easy to lay the cable due to a small cable diameter. Additional wire for signal transfer, e.g. power supply or rear-view camera signal.

Compatible with:

  • A1 (GB) since 09/2018
  • A3 5door Hatchback (8Y) since 03/2020
  • A3 4door Sedan (8Y) since 04/2020
  • A5 Coupé (F5) since 06/2016
  • A5 Convertible (F5) since 11/2016
  • A5 Sportback (F5) since 10/2016
  • S5 Coupé (F5) since 06/2016
  • S5 Convertible (F5) since 11/2016
  • S5 Sportback (F5) since 10/2016
  • RS5 Coupé (F5) since 06/2017
  • RS5 Sportback (F5) since 02/2019
  • A6 Avant (4K) since 06/2018
  • A6 Sedan (4K) since 06/2018
  • A7 Sportback (4K) since 02/2018
  • Q2 SUV (GA) since 09/2016
  • Q3 SUV (F3) since 11/2018
  • Q3 SUV Sportback (F3) since 08/2019
  • Q4 etron SUV (FZ) since 03/2021
  • Q4 SUV Sportback (FZ) since 03/2021
  • Q5 SUV (FY) since 01/2017
  • Q5 SUV Sportback (FYT) since 03/2021
  • Q8 SUV Coupé (4M) since 07/2018
  • e-tron SUV (GE) since 03/2019


NOTE:
Please check the size indications and the pictures of the camera for the compatibility with the vehicle, before buying!


Features:

  • Sensor type 1/3inch CMOS PC3089
  • Picture format NTSC
  • Resolution 720 x 480 Pixel
  • Min illumination 0.4 Lux
  • Angle horizontal 140°, vertical 105°, diagonal 180°
  • Mirrored image (fixed)
  • Parking guide lines, optional switchable
  • System cable with throughput, e.g. for reverse signal
  • Protection class IP69K
  • Colour of rear door opener handle and camera black
  • Total cable length 10m
  • Video connector RCA male connector
  • System connector camera 4pin BM
  • Diameter camera connector 5mm


Dimensions:

  • Overall 111 x 44 x 58mm (W x H x T)
  • Installation opening 105 x 40mm (W x H)



Operating voltage+12V DC (6V~16V)
Current consumption40mA
Power consumption0.5W
Weight incl. cable approx.230g
Operating temperature range-20°C to +70°C
AudiA1, Q8 4M, Q7 4M, Q7 4L, Q5 8R, Q3 F3, Q2, A7 4K, A6 4K, A6 4F, A5 / S5, A3 8P, A3 8L, A3 / S3, A1 GB
CategoryCameras RVC
